Solenoid valve

The MSV200 flameproof & dust explosion-proof solenoid valve is engineered for industrial sites with both gas and dust hazardous conditions. It supports 2-position 3-way and 2-position 5-way air circuit structure, with pilot-operated and direct-acting control principles optional.

This solenoid valve can be installed by surface mounting or pipe mounting. The operating temperature covers T6/T5/T4 temperature classes, with medium temperature ranging from -40℃ to 130℃. Standard voltages include 24VDC, 110VAC and 220VAC. It reaches IP67 ingress protection rating.

Available housing materials are aluminum alloy, stainless steel and brass. Air port connections support G1/4, 1/4NPT, 1/2NPT, while electrical connection adopts M20*1.5, 1/2NPT and other specifications. Widely used in chemical, pharmaceutical and other explosion-risk industrial automation control systems.

The MSV300 multi-type explosion-proof solenoid valve provides flexible explosion protection selections: flameproof, increased safety, dust explosion-proof and intrinsic safety versions, to match different hazardous working conditions. It features 2-position 3-way / 2-position 5-way air circuit structure, and can choose pilot-operated or direct-acting control mode.

It supports surface mounting and pipe mounting. The temperature rating covers T6/T5/T4, medium temperature from -40℃ to 130℃. Standard voltage options are 24VDC, 110VAC and 220VAC, with IP67 protection grade.

Aluminum alloy, stainless steel and brass housing materials are optional. Air port connections include G1/4, 1/4NPT, 1/2NPT. Electrical connection options include M20*1.5 and 1/2NPT. Ideal for complex hazardous environments in chemical, petrochemical and pharmaceutical process control.

The MSV400 solenoid valve supports two versions: flameproof & dust explosion-proof type for hazardous locations, and non-explosion-proof type for common industrial environments, helping customers save cost on non-explosion occasions. It adopts pilot-operated control principle and 2-position 3-way / 2-position 5-way air circuit structure.

The valve supports surface mounting and pipe mounting. Operating temperature covers T6/T5/T4, medium temperature range -40℃ ~ 130℃. Standard voltage: 24VDC and 220VAC, IP67 ingress protection.

Housing materials can be aluminum alloy, stainless steel or brass. Air port connections: G1/4, 1/4NPT, 1/2NPT. Electrical connection includes M20*1.5, 1/2NPT. Suitable for general and dust explosion risk automation pipelines.
